parc

parc hero showing a connected electric grid panorama with nuclear, hydro, solar, wind, substations, and transmission lines

Release Build status codecov Commit activity License

A model of Earth electric grid, from France to Japan, from nuclear plants to solar panel farms, from average power per site up to pressure in a pipe.

Motivation

How to compare French production to Italy production?

How to compute the monthly average renewable energy of Europe against USA?

What about EDF performance against RWE?

Any idea about the impact of quitting nuclear energy in Germany?

What hardware is used on prem here and there?

To answer these questions we need to represent our international grid on a common structure. I found none, so here is parc — an open source Python library to store, structure, and deliver public information about all electricity production systems.

Installation

Install the latest version directly from GitHub with uv:

uv add git+https://github.com/lakodo/parc.git

Install a specific branch:

uv add git+https://github.com/lakodo/parc.git@dev

Use with uv without installing

Run ecs-inspect directly from GitHub without adding anything to your environment:

uv run --with git+https://github.com/lakodo/parc.git ecs-inspect extract "check valve ASG021EC1 and pump RCV001PO"

ASG021EC1
RCV001PO-

You can also pipe the extracted references into validate:

uv run --with git+https://github.com/lakodo/parc.git ecs-inspect extract "check valve ASG021EC1 and pump RCV001PO" | xargs -I {} uv run --with git+https://github.com/lakodo/parc.git ecs-inspect validate {}

Query: ASG021EC1
Normalized: ASG021EC1
Exact Match: yes
Candidates: 1
Truncated: no

- type: rf
  raw: ASG021EC1
  canonical: ASG021EC1
  span: 0-9
  system: ASG
  system_label: Alimentation auxiliaire de secours des GV
  identification: 021
  base_function: 0
  order: 21
  material: EC1
  material_qualifier_meanings: Enclenché
  decomposition:
    tranche_segment: <absent> -> Tranche non précisée
    system_segment: ASG -> Alimentation auxiliaire de secours des GV
    system_letter_1: A -> Alimentation en eau - poste d'eau
    system_letters_2_3: SG -> Partie spécifique du trigramme système
    identification_segment: 021 -> Format compact sans sous-fonction
    identification_digit_1: 0 -> Fonction de base
    identification_digits_2_3: 21 -> Ordre 21
    material_segment: EC1
    material_bigram: EC
    material_qualifier: 1 -> Enclenché
Query: RCV001PO-
Normalized: RCV001PO-
Exact Match: yes
Candidates: 1
Truncated: no

- type: rf
  raw: RCV001PO-
  canonical: RCV001PO-
  span: 0-9
  system: RCV
  system_label: Contrôle chimique et volumétrique
  identification: 001
  base_function: 0
  order: 1
  material: PO-
  material_labels: Pompe
  decomposition:
    tranche_segment: <absent> -> Tranche non précisée
    system_segment: RCV -> Contrôle chimique et volumétrique
    system_letter_1: R -> Réacteur
    system_letters_2_3: CV -> Partie spécifique du trigramme système
    identification_segment: 001 -> Format compact sans sous-fonction
    identification_digit_1: 0 -> Fonction de base
    identification_digits_2_3: 01 -> Ordre 1
    material_segment: PO-
    material_bigram: PO -> Pompe
    material_qualifier: - -> Qualificatif absent ou non précisé

Quick start

Inspect a single unit

from parc.configs.edf.sites.nuc.belleville import BEL1

print(BEL1.name)
print(BEL1.power)
print(BEL1.design)

bel1
1300
FrenchNuclearUnitDesign.PP4

Browse an entire grid

from parc.configs.edf.france import FRENCH_GRID
from parc.constants.constants import UnitTechnology

nuclear_units = (
    (site, unit)
    for site in FRENCH_GRID.sites
    for unit in site.units
    if unit.technology == UnitTechnology.NUCLEAR
)

for index, (site, unit) in enumerate(nuclear_units):
    if index == 5:
        break
    print(site, "->", unit)

<site: "Belleville-sur-Loire" (2 units)> -> <☢️ FrenchNuclearUnitDesign.PP4 (1300): bel1 >
<site: "Belleville-sur-Loire" (2 units)> -> <☢️ FrenchNuclearUnitDesign.PP4 (1300): bel2 >
<site: "Blayais" (4 units)> -> <☢️ FrenchNuclearUnitDesign.CP1 (900): bla1 >
<site: "Blayais" (4 units)> -> <☢️ FrenchNuclearUnitDesign.CP1 (900): bla2 >
<site: "Blayais" (4 units)> -> <☢️ FrenchNuclearUnitDesign.CP1 (900): bla3 >

Query units by design

from parc.configs.edf.types import FrenchNuclearUnit

print(f"900 MW series : {len(FrenchNuclearUnit.get_900())} units")
print(f"1300 MW series: {len(FrenchNuclearUnit.get_1300())} units")
print(f"1450 MW series: {len(FrenchNuclearUnit.get_1450())} units")
print(f"1600 MW series: {len(FrenchNuclearUnit.get_1600())} units")

900 MW series : 32 units
1300 MW series: 20 units
1450 MW series: 4 units
1600 MW series: 1 units

CLI tools

ecs-inspect is a command-line tool to work with EDF Coding System (ECS) references found in documents or free text.

Extract references from a string

ecs-inspect extract "check valve ASG021EC1 and pump RCV001PO"

ASG021EC1
RCV001PO-

Extract references from a file

ecs-inspect extract-file report.txt

Validate a reference

ecs-inspect validate ASG021EC1

Query: ASG021EC1
Normalized: ASG021EC1
Exact Match: yes
Candidates: 1
Truncated: no

- type: rf
  raw: ASG021EC1
  canonical: ASG021EC1
  span: 0-9
  system: ASG
  system_label: Alimentation auxiliaire de secours des GV
  identification: 021
  base_function: 0
  order: 21
  material: EC1
  material_qualifier_meanings: Enclenché
  decomposition:
    tranche_segment: <absent> -> Tranche non précisée
    system_segment: ASG -> Alimentation auxiliaire de secours des GV
    system_letter_1: A -> Alimentation en eau - poste d'eau
    system_letters_2_3: SG -> Partie spécifique du trigramme système
    identification_segment: 021 -> Format compact sans sous-fonction
    identification_digit_1: 0 -> Fonction de base
    identification_digits_2_3: 21 -> Ordre 21
    material_segment: EC1
    material_bigram: EC
    material_qualifier: 1 -> Enclenché

Sources

All information in this library is public. Contributors should quote their public sources in the codebase when sharing information.

Useful resources

About the author

I'm PhD Joris GUERRY, research engineer at EDF (Électricité de France) until June 2026. Check out my LinkedIn profile for more.
